HEIMDALL Toolbox



Low image resolution processing with rapid
interpretation and low power.



Discover our toolboxes

HEIMDALL toolbox

The HEIMDALL toolbox functionalities consists of a low image resolution processing designed to offer rapid interpretation of images. HEIMDALL is suitable for multiple applications such as the detection of objects and intelligent motion interpretation. ASIC designs based on the HEIMDALL toolbox have already been used across a range of industrial and IoT applications for motion and luminance detection, object tracking, and data communication via RF links.

Want to test how the HEIMDALL toolbox fits with your application?

HEIMDALL possibilities



The Heimdall toolbox solution uses a low image resolution of 64×64 pixels, bundled with a core image signal processing to achieve a high-level classification of image content. The low number of pixels coupled with the optimized image signal processor results in short time and low power consumption. Using a silicon area of just 9mm2 for the RAM and image sensor, Heimdall is ideal for small IoT applications.

Heimdall_Toolbox



shutterstock_723907804 Optical Monitoring H400



Energy harvesting feature



Moreover, Heimdall can be combined with our energy-harvesting technology to create a single autonomous ASIC platform design that can capture, analyze, and re-act autonomously, while scavenging and harvesting its own energy from the environment. With no battery needed, it is the perfect fit and trade-off for motion and occupancy detection without any risk of privacy violations carried by sophisticated computing vision solutions.

HEIMDALL APPLICATION DOMAINS

ASIC building & infrastructure

Building and infrastructure automation

> Occupancy and people Counting
> Smart Lighting
> Factory access control and automatic doors
> Highway & traffic surveillance/vehicle counting

ASIC design prodcution

Production infrastructure

> Smart Agriculture including pesticide detection (NIR) levels

> Food and material quality inspection and sorting automation

ASIC design security surveillance safety

Security, Surveillance and safety

> Factory line Smart Safety (Safety alarms)
> Complement to Video Surveillance and intrusion detection
> Eyewear protection

iStock-840878894

Test and measurement

> Chemical Analytical composition
> Material inspection
> High Dynamic Intrusion
> High dynamic global shutter optics
